Raw Materials in Legos
Legos are an essential part of a child’s adolescence. They help build the foundation for creativity and play. The Lego Company was first founded in 1932 by Danish carpenter, Ole Kirk Christiansen. Originally starting with cellulose acetate, the company now uses acrylonitrile butadiene styrene to create the small blocks. Acrylonitrile butadiene styrene, abbreviated to ABS, is a common thermoplastic used in many products. These toys go through a long process to be made. First, raw materials are needed to start the cycle, which then go through the production system, forming the mold of the blocks and finally the excess waste that comes out of the entire life cycle. According to the UK Sustainability Report of the Lego Group in 2007, the raw materials used for the plastic toys are from crude oil and natural gas. From their 2012 Progress report, it is stated that their long term goal is to “generate enough renewable energy to balance our ongoing energy needs”. Last year, the LEGO Group reached a recycling rate of 88% and is in the process of planning a wind park to balance the energy consumption. The raw materials used are approved by the company to be safe. ABS is the main plastic used in the production of LEGO bricks. Acrylonitrile, butadiene, and styrene go through various processes to become the thermoplastic they are used for. Found in the earth then modified and extracted, these raw materials go through a long way to become the LEGO bricks we know today.
Crude oil is the main source of ABS. It goes through several chemical processes to convert the large molecules in crude oil into smaller molecules to make a chain for the plastic. Plastics are very popular because they can be changed easily and customized by varying the atomic structure. Acrylonitrile is very flexible, tough and has high strength; it “is often copolymerized with other monomers to form fibers”. In addition to these characteristics, it contributes to heat resistance and chemical resistance when combined with butadiene and styrene. Butadiene adds “higher impact strength, toughness, low-temperature property retention, and flexibility”. Lastly, styrene provides “rigidity, glossy finish, and ease of process ability” One of the most common ways of processing ABS is by graft polymerization of acrylonitrile and styrene onto a polybutadiene latex, blending it and drying the result. Another way is to manufacture the three polymers separately from the styrene-acrylonitrile latex and then blend and dry.
Acrylonitrile is made up of propylene, ammonia, and oxygen. These chemicals go through the Sohio process made by The Standard Oil Company. “This process is a single-step direct method for manufacturing acrylonitrile from propylene, ammonia, and air over a fluidized bed catalyst”. Presently, more than 95% of Acrylonitrile in the world is produced by British Petroleum, which bought The Standard Oil Company in 1987. The Sohio process started out as a way to “use metal oxides to convert hydrocarbons to oxygenates”. After seeing the success of this process, scientists continued to develop this idea to further extract materials. Following the succession of several tests to create acrylonitrile, a more efficient method was derived to produce acrylonitrile directly from propylene. This was done “by carrying out the entire reaction in a single step with bismuth phosphomolybdate, […resulting] in ammoxidation, a process that produced acrylonitrile in about 50 percent yield with acetonitrile and hydrogen cyanide as co-products”. Acrylonitrile by itself “evaporates when exposed to the air [and] it dissolves when mixed with water”.
Butadiene is one of the “most produced chemicals in the United States”. Some physical characteristics of butadiene are that it is soluble in acetone, alcohol, benzene, and ether. It is produced “by extractive distillation from crude butylene concentration (C4) stream, a by-product of ethylene and propylene production”. A report on the processing of butadiene states that, “over 95 percent of butadiene is produced as a byproduct of ethylene production from steam crackers and recovered via extractive distillation”. This shows that the main source of butadiene comes from ethylene by steam crackers and that distillation is the main way to extract this chemical. Extractive distillation is needed to purify the butadiene “because the boiling points of the components of crude butadiene are so close together”. In this process, the crude butadiene is placed into a column and washed with an extraction solvent. Lighter, less soluble components referred to as C4 Raffinate 1 go out the overhead of the column, while the bottom product contains the extraction solvent, the butadiene, and other materials. Then, this “butadiene-rich bottoms” is fed to another column where the solvent is recovered and reused. The butadiene continues to go through further distillation to remove all impurities before the purified butadiene is finalized, usually greater than 99.5%. Finally, the butadiene is packed carefully as a liquefied or compressed gas. This is the most common way butadiene is extracted from ethylene.
Three additional methods to license and produce butane is by hydrogenation or fractionation, by orbutene®, or by SABIC developed ethylene dimerization. There are a variety of ways of obtaining butadiene depending on the type. Isobutylene is mainly made by using these four methods: MTBE Decomposition, TBA Decomposition, Isobutane Dehydrogenation, and Cold Acid Extraction. Interestingly, butenes can be found in corn. Some health risks of butadiene include increased risk of cancer, irritation in the eyes, nose, and throat, drowsiness and lightheadedness. Butadiene has low-water solubility and evaporates when exposed to the environment. Although this chemical has many threats, if it is handled carefully, then there is no harm. Additionally, the LEGO Group makes sure that the substances used in the making of their toys are not harmful to people.
Styrene is composed from petroleum and natural-gas products. It is a clear liquid that is often used in many products because of its versatility. This material is made in petrochemical plants in the United States and around the world. There are several other ways to produce styrene, such as the conventional ethylbenzene dehydrogenation process, extracting styrene from methanol and toluene, the TOTAL/Badger Styrene Process, and the Lummus UOP SMARTTM SM Process. There are many more other ways to get styrene, all having similar procedures but differences in the catalysts used, chemicals, and machines. The process of obtaining styrene via benzene and ethane starts by feeding ethane and ethylbenzene to a dehydrogenation reactor with a catalyst. This catalyst is capable of producing both styrene and ethylene. Next, the dehydrogenation reactor effluent is cooled and separated as the ethylene stream is recycled. A flow chart of this process, developed by Snamprogetti S.p.A. and Bow is shown in Figure 1.
This liquid is very popular and in constant demand. Consequently, “styrenics producers are [continuing] to restructure, and close less competitive plants in order to boot and restore profitability”. Figure 2 shows the consumption of styrene in the United States. Interestingly, styrene can be found in the environment and in common foods like coffee, strawberries, and cinnamon. It is named after styrax trees, which give off benzoin from their sap. From the benzoin, styrene can be extracted. The molecular formula, C8H8, shows that it consists only of carbon and hydrogen. Styrene has a particular smell that can be detected even at low levels, but it is not harmful to one’s health. Similar to acrylonitrile and butadiene, styrene disappears quickly when exposed to the air. Years of testing show that it is not harmful to workers or to people who are exposed to it for long periods of time.
Using the combined three elements, many companies around the world use ABS in their products. It is a popular material to use, but despite its many desirable attributes, there are some drawbacks to ABS such as “the opacity, poor weather resistance, and poor flame resistance”. However, ABS is recyclable and many appliances reuse the ABS from products in their new products. As one of the leading thermoplastics, the “thermoforming industry [today] has been a leader in the recycling effort because it simply made good business sense”. The LEGO Group recycles their products in a different way than most people think of recycling. According to their 2012 Progress Report, LEGO Group believes “in producing high quality products that last year after year, maybe for generations”. They do recognize that using raw materials for producing, packing, and distributing impact the environment and are currently trying to increase their efficiency and energy usage. Approximately 60% of the total carbon dioxide emissions arise from the raw materials used in the production of LEGOs. LEGO is trying to improve their resources and their sustainability. In this same report, employees found that more than 60% of the discarded plastic waste could be recycled. Over the past year, a total of 279,000 m3 of water was used.
The initial search for raw materials was not difficult, but overwhelming at the amount of information there was to cover. However, as the research began, it became harder to find new materials on the subject. A lot of the sources contained the same information and did not go into depth on the processes of producing ABS. After much searching, there was a report on the production of butadiene and another report on producing pure styrene. However, there was no luck in finding a detailed account of how to obtain acrylonitrile. The LEGO Group has very informative accounts of their progress each year, which was very helpful in learning more about the company. Though the reports are from the company’s viewpoint, consequently having a biased outlook, the facts and percentages stated can be taken as truth. Much of the information was found online and through e-books. It was very difficult to find books that contained the information needed. Focusing on just the raw materials assisted on learning how certain plastics were made and what qualities different materials have. ABS, being a common plastic, had a lot of general information, each article found, stating the same knowledge. Several sources were identical in describing the raw material is.
The LEGO Group has produced millions of these bricks and is established as a successful toy company. They have pledged to improve their sustainability and the raw materials used in the production of the plastic bricks and figures. All the raw materials originate from crude oil and are tested to make sure they are safe. The LEGO Company aims for a higher energy efficiency and zero wastes. In addition, the creation of their own wind farm will aid in producing their own energy sources. Starting from 1958 until today, the LEGO Group has used plastics in the processing of their toys. Acrylonitrile, butadiene, and styrene are the main raw materials used in creating these popular blocks and continue to aid in the success of the company.
